Electric Eco-Delta SX
- Economical Delta Recumbent
- 20 mph Top Speed / 10-44 Mile Range*
- Comfort High Seat for Easy Mounting
In-Stock 5-6 day processing.
$250 flat-rate to Contiguous USA Only
The Eco Delta SX is the most affordable SUN delta trike and it's full of features. It has a fully adjustable mesh-back saddle with a padded bottom that keeps you cool and comfortable. There are spare bottle mounts on the handlebar and seat frame.
Setting this electric trike apart from others is its traditional handlebars, higher seating position and lower cranks better suited for casual riding. This e-trike utilizes the compact yet powerful 1000w performance electric drive system paired with a 36 volt Li-ion battery pack for 20 mph top speeds and plenty of torque.
| Model | Weight | Range | Mount Style | Cost |
| 36v 9ah Shrink Wrapped | 4.4lbs | 10-22 | Battery bag with velcro straps | Base Cost |
| 36v 10ah Aluminum | 7.7lbs | 12-26 | Sliding plate with lock | +$210 |
| 36v 20ah Shrink Wrapped | 10.6lbs | 20-44 | Battery bag with velcro straps | +$330 |
Battery Option Overview:
Videos, written instructions and links related to the electrical system and the conversion process that was performed on this tricycle. Specific tasks and additional parts needed to convert this trike in the best possible way.
Conversion Points:
- Install the torque arm on the drive-side (non-wire side) front of the fork
- Use ½” pipe clamps to mount battery plate to backrest struts. File ¼” from the rear of the two rear mounting slots on the battery plate
- Mount the screen on the handlebars
- Mount twist throttle above grip sifter. Cut down grips to fit
- Only use left hand e-brake. Right stays with double-pull brake
Kit Model: E-BikeKit GRD5FH 20”
- 1 left locking e-brake
- One brake dongle
- Split-twist throttle
- Modify stock grips
- No plate mounting screws
Additional Parts:
- No grips, cut down stock grips
- Standard m6 battery plate mounting screws
- 4x B&B hardware - Pipe clamps 1/2”
- J&B Importers #34395 - To peak bar extender computer mount
Highlights:
- Most affordable recumbent
- Easy mounting higher seat
- Comfortable upright seat
- Traditional high handlebars
- Simple 1x7 gearing
- Ideal for longer rides
- 4 x water bottle mounts
Tricycle Specifications:
- JB Part #670113
- Wheel Base: 42.5"-63" (126-160cm)
- Overall Length: 68.75"-82.25" (125-209cm)
- Width: 30.5" (77.5cm)
- Seat Height: 20.5"-22.75" (52-58cm)
- Weight: 57lbs
- Weight Limit: 300lbs
- X-Seam: 31"-53" (31-79cm)
Highlights:
- 1000w peak power
- 20 mph top speed
- 12-26 mile range
- 36v10ah Li-ion Battery
- USA hand-built wheel
- 5-level top speed control
System:
Watts (Nominal/Peak): 500-1000w
Top Speed: Approx. 20mph
Range: 10-26 Miles
Charge Time: 3hrs (0-100%)
Weight: 21lbs (9.5kgs)
Motor:
Brand: Electric Bike Technologies
Type: Internally Geared (brush less)
Power: 500w nominal / >1000 @48v
Max Torque: 84N-m @48v
Max RPM: 320 @48v
Cable: 8" axle exit, 3-phase / 5 hall effect
Connector: Round 8-pin 13/32" (10.4mm)
Weight: 9.4lbs (4.26kg)
Battery:
Range: 10-20 Miles (Rider Weight, Rider Input and Terrain Contingent)
Charging Time: 10ah pack = 4hrs / 2.5Amp Charger = 2.5 amps charged per hour
Nominal Voltage: 36v
Nominal Capacity: 10Ah (0.2C)
Battery Energy: 360Wh (Approx.)
Dimensions: 11.7" (297mm) x 6" (148mm) x 2.7" (68mm) (Approx.)
Total Weight: 7.7lbs/3.5kg
Cell Assembly: 18650-3.6v-10S5P
Life Cycles: 80% Dod = 1200 cycles
Max. Continuous Discharge: 22.5A
BMS Protection Current: 30A
Discharge Cut-Off Voltage: 30v
Max. Charge Voltage: 42.5v
Inner Resistance: <= 130mΩ
Charge Time: <= 3.3 hours
Operation Temperature Range: Charge: 0’C---45’C / Discharge: -20’C---60’C
Storage Temperature: 0’C---40’C (Extended Storage: 15’C-25’C;)
Battery Case Material: Aluminum
Assembled Pack Certificates: UL; UN38.3; MSDS; RoHS; SGS
Limited Warranty: 1 Year
Manufacturer: Electric Bike Technologies
